Dual Revolution Watermelon Wiring Kit

Dual Revolution Watermelon Wiring Kit

The Dual Revolution Watermelon Wiring Kit includes everything required to power and control your Dual Revolution Watermelon lights — from the batteries, through the relay control module, all the way to the lights themselves.

This kit is designed as a complete plug-and-play wiring solution, removing the guesswork from installation while ensuring high-current power is handled safely through relays, not your dash switch.

All components are pre-terminated with quality Deutsch connectors and are designed to work together as a modular system.

Kit includes:

• 1 × Battery Power Feed
  Supplies fused power directly from the batteries to the relay control module.

• 1 × Relay Control Module
  Uses two relays to supply high power to the lights without loading the dash switch.

• 1 × Dash Switch
  Please add a note at checkout to specify either:
  Glass Watermelons or It’s Melon Time text.

• 1 × Dash Switch Power Kit
  Provides power and illumination for the dash switch.

• 1 × Power Spine
  Distributes power cleanly along the chassis to multiple lighting locations.

• Splitters, fused light joiners, and extension leads
  Supplied based on kit size selection (8-kit, 10-kit, or 12-kit) to suit your lighting layout.

• 1 × Cable tie pack

• H11 36watt Glass Watermelons
  Supplied based on kit size selection (8-kit, 10-kit, or 12-kit) to suit your lighting layout. Please add a note at checkout to specify Dual Revolution Colour


Installation:

This system is fully plug and play.
Only basic wiring is required to connect the dash switch, following the simple wiring diagrams supplied. No cutting, soldering, or custom wiring is needed.

Designed for expandable underglow and chassis lighting setups, this kit allows you to build anything from a clean dual-colour setup to a full high-output Glass Watermelon lighting system with confidence.
